Hebei Jiede Medical Equipment Co., Ltd. specializes in the manufacturing and global distribution of high-performance manual and electric wheelchairs. Our wheelchair products are designed to meet the rigorous demands of hospitals, nursing homes, rehabilitation centers, and home-care environments.
We offer two flagship wheelchair series:
Manual wheelchairs for daily mobility and toileting assistance
Compact electric wheelchairs with ergonomic controls and indoor-outdoor compatibility
All models are manufactured in accordance with ISO 13485 quality standards and certified by CE, ensuring compliance with international medical device regulations.
| Specification | JD-L Series (Manual Wheelchair) | JD-L09 Series (Electric Wheelchair) |
|---|---|---|
| Frame Material | 22mm diameter carbon steel tubing, 1.0mm wall thickness | Lightweight foldable aluminum alloy |
| Max Load Capacity | 150 kg | 120 kg |
| Rear Wheels | 24-inch aluminum alloy spoke wheels | Solid rear wheels (electric motor integrated) |
| Front Wheels | 7-inch solid PVC wheels | 8-inch PU wheels |
| Braking System | Dual rear brakes + dual parking brakes | Electromagnetic braking system |
| Seat Material | 600D Oxford cloth with sponge padding | High-density cushion with waterproof cover |
| Commode Function (Optional) | U-shaped seat with pull-out ABS waste basin | Not available |
| Folded Dimensions | 88 × 24 × 90 cm | Compact size, fits car trunk; net weight < 30 kg |
| Motor Type | N/A | Dual brushless motors with intelligent control system |
| Battery | N/A | Lithium battery, travel range up to 20 km per charge |
| Speed | N/A | Adjustable up to 6 km/h |
| Controller | N/A | Joystick (360° control, left/right switchable) |
| Customization Options | 4 fabric types, 3 commode types, OEM logo/packaging | OEM support (frame color, branding, packaging) |
| Typical Applications | Hospitals, nursing homes, long-term care, rehab centers | Home care, urban mobility, elderly transport |
| Certifications | ISO 13485, CE | ISO 13485, CE |
Selecting the appropriate wheelchair depends on the user’s mobility level, application scenario, care environment, and transport requirements. Below are key considerations to help you make an informed choice between manual and electric models:
Choose this series if:
The patient has some upper body strength or will be assisted by a caregiver
Toileting support is required (commode version available)
The product is mainly used indoors (hospital wards, nursing homes, clinics)
You need a cost-effective, durable, and low-maintenance solution
Limited storage or transport space is a concern (folds to 88 × 24 × 90 cm)
Choose this series if:
The user requires independent mobility and cannot self-propel
A comfortable long-distance solution is needed (range up to 20 km)
The product is used both indoors and outdoors
Joystick control and easy maneuverability in tight spaces are priorities
Lightweight and portable models are preferred (net weight < 30 kg)
